The tractor can accomplish various farm works when attaching different farm implements, such as hole drilling, plowing, rotary tilling, harrowing, seeding, harvesting, spraying, grass cutting and transportation as well, and also can be equipped with front end loader and back hoe.
1. Streamline shape design, baking finish, elegant and luxurious.
2. Equipped with LR6M5-23 diesel engine, natural aspiration, low fuel consumption and high reliability.
3. 4*(3+1)*2 gearbox provides you 24 forward and 8 reverse gear shifts.
4. Full hydraulic steering, independent dual-stage clutch, hydro static disc brake.
5. Cabin, ROPS, air brake for your options.
Our smooth-shifting, fully synchronized transmission with 16 forward gears and 8 reverse gears could provide you amazing efficiency. With the high range for travel speed, medium range for mowing and low range for hard-pull applications and loader work, provide you the power you need for the task at hand. That means you`ll always be able to make a proper gear selection in a wide speed range according to the changes of circumstances, the function of different farm implements, the changing of speed.
You can also choose to install the crawling gear structure which could double the number of the gears and provide you better traction when you have tougher tasks.
Tilting traction structure effectively reduces the impact load and tractor vibration, the driving experience is more comfortable while making the connection structure more durable.
Full Vision cab with frameless glass cover, provides maximum field of vision for you, making it safer to operate the tractor.
Using plastic strips to seal the whole cab, which could effectively cut off the noise from external environment, gives you an excellent sealing performance.
The operator-oriented designing idea and ergonomic interior layout, make every button in the cab around you clearly marked and easy to touch. Equipped with heater, you can choose to install air conditioning get a more comfortable and pleasant driving experience.
Mechanical hydraulic seat with armrests and headrest could provide you an adequate support. That means it could provide you complete comfort and confidence by effectively reducing turbulence generated during operation when you operate in the toughest of territory.
Hydraulic output is optional, making your tractor match more kinds of farm machinery and implements, to meet your different demands.
Paddy wheel is optional, making it adapt to different working conditions
Model | TE800 Tractor | TE804 Tractor | |
Drive Type | 4×2 | 4×4 | |
Engine | | | |
Engine Manufacturer | YTO Group Corporation | YTO Group Corporation | |
Engine Model | LR4B5-23 | LR4B5-23 | |
Engine Type | vertical,water-cooled,four-stroke,direct injection | vertical,water-cooled,four-stroke,direct injection | |
Max Torque(N·m)/Revolving Speed(rpm) | ≥330/1700 | ≥330/1700 | |
Displacement(L) | 4.95 | 4.95 | |
Cylinder Diameter * Stroke | 108×135 | 108×135 | |
Fuel Tank Capacity(L) | 150 | 150 | |
Engine Rated Power (kW/rpm) | 59 | 59 | |
Rated Operating Conditions Fuel Consumption Rate(g/kW·h) | ≤242 | ≤242 | |
Drive Train | | | |
Clutch | dry,single disc,independent dual-stage | dry,single disc,independent dual-stage | |
Standard PTO speed(rpm) | (760，1000)/(540，1000) | (760，1000)/(540，1000) | |
Gears | 8F+4R/16F+8R(creeper) | 8F+4R/16F+8R(creeper) | |
Steering type | hydraulic steering | hydraulic steering | |
Gear Shift Mode | meshing gear shift | meshing gear shift | |
Speed Range(Km/h) | 0.41～31.11 | 0.46～34.85 | |
Break System | | | |
Service Brake | pedal,mechanical drive,hydrostatic,disc | pedal,mechanical drive,hydrostatic,disc | |
Parking Brake | handle operation, | handle operation, | |
Hydraulic System | | | |
Hydraulic Output Flow(L/min) | 50 | 50 | |
Hydraulic Output Valve | 2 ways | 2 ways | |
Working Device | | | |
Three-Point Suspension | postposition,Category Ⅱ | postposition,Category Ⅱ | |
Max.Lifting Capacity(kN） | 14.2 | 14.2 | |
Tillage Depth Adjustment | draft and position adjustable,floating control | draft and position adjustable,floating control | |
General Parameter | | | |
Overall Dimension(L×W×H)mm | With cab | 4027×2050×2670 | 4027×2050×2750 |
Without cab | 4027×2050×2670 | 4027×2050×2750 | |
Wheelbase(mm) | | 2210 | 2195 |
Min. operating weight(kg) | With cab | 3600 | 3873 |
Without cab | 3350 | 3683 | |
Min. Ground Clearance(mm) | | 418 | 375 |
Min.turning radius(mm) | 3400 | 4200 | |
Front Tire | 6.5-20 | 11.2-24 | |
Rear Tire | 14.9-30 | 16.9-34 | |
Rated Pull | 15.5 | 18.6 | |
Optional Disposition | | | |
| hydraulic pressure lifter, | hydraulic pressure lifter, | |
Beifute Company has established an ERP management system and advanced performance testing and chemical testing centers. It has introduced specialized equipment such as spectral analyzers, pressure testing benches, hardness machines, tensile testing machines
Beifute Company has established an ERP management system and advanced performance testing and chemical testing centers. It has introduced specialized equipment such as spectral analyzers, pressure testing benches, hardness machines, tensile testing machines
■ Equipped with 4 cylinder engine,direct injection engine, start convenient,low fuel consumption,high traction, high reliability and high coefficient of torque reserve. ■ With heavy-duty chassis,high traction,and high double-speed PTO shaft,it works more efficiency. ■ Transmission gears 8F+2R ,optional reversing device 10F+2R,featuring reasonable speed-matching,high working efficiency,and good fuel economy in all kinds of farmland homework and transportation. ■ Equipped with the side operation control device and the shift sleeve device,featuring convenient,comfortable,and reliable control. ■ Reinforced dual-speed power take-off, featuring the wide range of optional machinery and tools and high reliability. ■ Hydraulic lifting device adopted position control and float control, easy to operate and provides reliable performance. ■ The complete vehicle adopts the optimized ergonomic design to improve the driver’s safety feeling,and the comfort to control. ■ A new generation of steamline hood,with beautiful and elegant appearance,conforming to the safety,dust-proof,noise-reduction,heat-removal and other performance requirements. ■ Light and better sealed, give it high performance in paddy field farming. ■ Provide EC,EPA,GOST certification model.
The TE chassis tractor is a robust and versatile agricultural machine designed to meet the diverse needs of modern farming. With its advanced features, exceptional performance, and comfortable design, it is ideal for a wide range of field operations.
TE504 Dapeng King (King in greenhouse) Tractor is specially designed to meet the needs of greenhouse and orchard environments, while also accommodating general fieldwork requirements. It is a multi-purpose wheeled gardening tractor powered by a vertical four-cylinder diesel engine, combining compact structure, strong power, and flexible operation.
The TE504 flat floor tractor features a cab design and has been enhanced in both functionality and comfort to excel in a variety of tasks, including lawn care, construction projects, small farm work, gardening, greenhouse operations, and more. Significant improvements in ergonomics ensure a more comfortable and convenient operating experience, while also simplifying maintenance. This versatile tractor is well-suited for multi-purpose use, gardening, transportation, orchard work, greenhouse tasks, and general fieldwork.
