China 12hp-22hp Mini Tractor for Efficient Farming and Gardening

China Mini Tractor | Compact Tractor:

The China mini tractor is a belt-driven mini tractor designed for agricultural work in the yard.

Advantages of the Mingsin China Mini Tractor | Compact Tractor:

Differential lock;

The basis of a mini-tractor is a special motor-tractor chassis;

The worm steering mechanism - provides better maneuverability;

Full tractor transmission;

Rear-view mirrors, front fenders;

Oil pressure gauge, coolant temperature gauge and ammeter on the dashboard.

The China mini tractor is equipped with a two-section hydraulic distributor. Thanks to it, many types of attachments can be attached to the mini-tractor.

The Mingsin China mini tractor performs the following tasks:

Tillage with plough and cultivation with tiller;

Planting and harvesting by planter and diggers;

grass mowing with mowers, including rotary;

snow removal with a snow blade;

transporting loads using a trailer.

The Mingsin China  mini tractor is manufactured in China by Mingsin. It is a low-cost but reliable tractor, and it is very popular in China and East Europe.

Only high-quality components are used in the production, which has a positive effect on the quality of the finished machine. In addition, at all stages of production a strict quality control is carried out.

The advantages of the model

1. Reliable diesel engine;

2. Unique direct injection 40 DI-EM system improves combustion efficiency, resulting in an average fuel consumption of 1.2 - 2 litres/hour. The engine is quieter than other counterparts.

3. Equipped with a planetary (full-featured) centre differential, which increases flotation and reduces wheel wear;

4. HYDRAULICS. 4 modes of operation: the forced lowering of the piston enables to deepen the attachment to the required depth; the locking mode in any position; the floating mode, due to which the equipment follows the terrain; the forced lifting mode;

5. The chassis is made of a robust welded 2 beam frame;

6. The base frame is longer than that of similar tractors of other brands.

7. There is a more comfortable seating position for the driver, the operating elements are not close to the fenders or the seat, and the pedals are conveniently located.

8. The track is adjustable from 1,080 to 1,450 mm;

9. V-belts last up to 3,000 m/h with correct tension adjustment;

10. Dry disc clutch, made from an ultra-durable material, with a smooth and easy to engage gear;

11. Transmission housing is made from high quality cast iron with magnesium added, making it resistant to gear shocks. Transmission shafts are made from alloy steel, making it three times as strong;

12. Front axle steering linkages have been redesigned for a tight turning circle and improved ease of steering;

13. AISIN oil seals of high quality protect the axle from any oil leaks and do not let up even under constant vibration;

14. Hydraulic cylinder positioned high up, to protect it from dirt and dust;

15. Versatile hitch - while standard mini tractors work with attachments of the brand under which it was released, the Mingsin MS150 allows you to use the equipment of other manufacturers;

16. Reinforced design of rear hitch - the problem of shaft breakage on one-point hitch is corrected, work with attachments under increased loads, for example, soil tiller;

17. Variability in machine starting - both the electric starter and the decompression valve are included to help start the machine with a crooked wrench;

Availability of spare parts - if anything happens to the machinery, it is easy to replace the broken part.

Quality of assembly. Personal quality control of each tractor + inspection by the Quality Assurance Department.

Considering all the advantages of the Mingsin China mini tractor, you can conclude that it is a truly profitable

China Mini Tractor

China mini tractor Mingsin differs from its predecessors with increased power. This model will be relevant for use on difficult surfaces such as soft, marshy ground. The power of the Mingsin China mini tractor is 12 hp-20hp, the diesel engine is known for its quality and durability, and has a high traction.

Technical characteristics of Mini-tractor Mingsin China mini tractor:

• Reliability and quality of design.

• The Mingsin China mini tractor is equipped with a reinforced frame for easy attachment of heavy attachments without any harm to the equipment, and a reinforced driving axle ensures that the technique can withstand the load even when the maximum track is set.

• Constant V-belt tension to transmit power enables you to work with confidence and make sure power is delivered without any loss, because the technology prevents V-belts from slipping onto the pulleys.

• Dual cutter drive chain is designed to increase service life and minimum risk of breakage

• Perforated idler pulleys are fitted to extend belt drive life

• The gearbox is made from QT500, a cast iron and graphite alloy that proves its durability. This material is one of the toughest alloys available, capable of withstanding the highest stresses.

• For long and continuous operation, the engine is cooled by a liquid cooling system, which allows the tractor to work for 10 hours without interruption. The manufacturers pay particular attention to their products, choosing only high quality and durable alloys.

• Of course the famous and robust hydraulics (upper cylinder position) not only allows large hydraulic stroke but also protects against dirt ingress, which increases service life

Extended hydraulic system

The Mingsin China mini tractor is equipped with a 2-vector hydraulic system, which allows the tractor to connect two types of attachments at once, which significantly reduces operating time and will be especially relevant for municipal tasks, for example, you can connect a dozer blade and a brush at the same time. And there are three positions available: raised, lifted and floating.

Economical operation and maintenance

• Low fuel consumption of 1,900 grams/moto-hour is a major conservative factor.

• The durable material used for the construction of important components in the Mingsin mini-tractors reduces the risk of breakdowns and the frequency of component replacement, saving you money. The quality of the machines is also double-checked, and our company is responsible for every unit during the warranty period.


• If you do have to resort to purchasing spare parts, you can easily do so. A wide range of parts at affordable prices is available on the market


• Versatility of use and a wide range of technical specifications


• Track setting, which is important for the planting and cultivation of different kinds of plants. Can be set between 1000 to 1200 mm


• Electric starter an important feature, especially if the tractor will be used in cold weather


• Reliable 6-speed transmission, with three forward and two reverse gears. Gives an easy acceleration up to 40 km/h


Many kinds of devices and implements can be connected depending on the job at hand, and it is also possible to fit a power tiller

1. Tillage tiller

2. Diesel engine

3. Gearbox

4. Manual throttle - variable speed control

5. Adjustable track width

6. Hydraulics in 3 positions

7. Differential lock

8. Electric starter

9. Headlights, lights

10. Door horn

11. Door mirrors

12. Wheels with industrial tread

13. Spare parts kit

Main Features

• Compact,Agile,Light,Reliable,Convenient,High Quality.

• Suitable for dry fields in plain, mountain and hilly areas. Attached with the implements, it could finish the work of tilling, plowing, mowing, reaping, harvesting, irrigating and so on. When attached the trailer, it also could be used for the short distance transportation.

• Can be used as a stationary power source for drainage and irrigation.

• With quick coupling,easy to change farming implements.

• Different product colors is optional, to adapt to different market

China mini tractor

Main Features

Compact,Agile,Light,Reliable,Convenient,High Quality.

Suitable for dry fields in plain, mountain and hilly areas. Attached with the implements, it could finish the work of tilling, plowing, mowing, reaping, harvesting, irrigating and so on. When attached the trailer, it also could be used for the short distance transportation.

Can be used as a stationary power source for drainage and irrigation.

With quick coupling,easy to change farming implements.

Different product colors is optional, to adapt to different market

The first review of the tractor.

At the first inspection of the China mini tractor, we got the first impressions of this model, which includes the latest developments for this class of equipment - mini tractors weighing up to 700 kg.

The tractor became stronger, the vibration decreased, due to the fact that the load-bearing frame became more powerful. The long-awaited adjustment of the track has been added to the tractor - now the distance between the wheels can be adjusted from 105 to 140 cm. The Mingsin Mini tractor can be used both in gardens with frequent growths of trees (the China mini tractor has the smallest turning width among its class models) and when working with Potatoes - planting, inter-row processing and excavating is ideally done when the wheels are placed at a maximum width of 140 cm.

From the minuses of this design, we can see the fact that the rear wings are not adjustable in width, and with the narrowing of the rear wheels, the hub itself still does not become smaller.

China mini tractor was equipped with a hydraulic pump with a two-channel hydraulic distributor. What does it mean?

Previously, to install on the tractor front attachments (for example, a mower, or a snow dump), it was necessary to change the hydraulic hoses from the rear to the front. This created a certain discomfort - it was necessary to follow that hydraulic oil after this procedure remained at the desired level, and the time was lost. Now - once you put the hoses on the front hinged, you get rid of this procedure almost forever. Simply disconnect the hinged itself, leaving the front hydraulic hoses with the cylinder in place, and if necessary, simply attach it to the adjustable fastener (it was previously fixed in the frame itself, and now it is adjustable in two axes). Adjusting the position of the front mounted is now as effective as possible, say goodbye to the skewing of the belts because of the inconsistency of the pulleys! The motor is now equipped with a five-drive pulley. Now, to install the mower, you do not need to remove the hood.

To use the front and rear attachments at the same time is now elementary.

On the tractor completely revised the warning system sensors (dashboard). If earlier the coolant temperature and oil pressure sensors in the diesel engine displayed warning signals (worked yes / no), now the temperature is correctly displayed on a scale of degrees Celsius, and the pressure is correctly displayed in kg / cm.cub. (Approximately 1 bar). What really did not suffice is the engine hour meter, for the correct measurement of the operating time, and the onset of the planned maintenance; By the way, a small mistake has been fixed - the oil drain plug in the pallet has been transferred. Now it is much more convenient to drain the oil.

The ammeter was moved down, and made it electronic, not mechanical.

As always, Mingsin mini tractor are democratic prices and excellent quality of every detail. The already well proven system of switching on and off the lock of the tractor differential (rear axle) with forced switching is now used on many models of "mingsin" China mini tractors. Tractors, prices for which today can fluctuate significantly from the current dollar exchange rate will never let you down on the site, and will greatly facilitate your country life.

When buying tractors "Mingsin", you will receive a complete set of documents for its registration. To put the tractor on the register, or not to put? You decide. On the one hand, the case is troublesome, registration in China, obliges you to pay a transportation tax, have the rights of a tractor operator (without them you will not get state numbers), and many Mingsin owners are rarely chosen for public roads. On the other hand, having once taken care of the legality of owning a vehicle, you will no longer have problems with traffic, no one will ask you questions when driving on a country road - everything is legal. The tractor is equipped with light and sound signals - headlights of far and passing light, turns, horns.

Excellent technical refinement, no less important when working with a milling cutter and a two-hull plow. The China Mini Tractor has a hydraulic distributor with a floating mode function. Accordingly, a double-hull plow and active rototiller (this hinged comes in the kit) are fitted with wheels for adjusting the burying. Why is this function necessary? In its absence, the operator of the tractor needed to monitor the conditions of the terrain during plowing or cultivation. It was necessary to constantly monitor - did not the milling cutter too deep? Did the plow "drown"? With any change in the terrain, it was necessary to control the position of the hinged. As a result, the work boiled down to the fact that the operator looked all the time, not forward, but back, controlling the degree of penetration of the hinged. The same was true for working with soot, seeders and potato diggers. Now you can forget about this problem! Set the required depth on the adjusting wheels, turn on the "floating mode" - voila! Floating mode is installed in all mini tractors produced with the latest time. To switch it on you need to maximally extend the hydraulic cylinder (switch and hold the lever in the lower position). Thus, the oil from the distributor will return through the oil return tube to the tank. Then squeeze the clutch pedal and lower the hydraulic cylinder to the lowest position. After this, the hydraulic cylinder will go into a free position and the attachments will function under their own weight.

Parameters:

QC Flow:

1. Material inspection before production to avoid any potential problem from  the very beginning.

2. Inspection for half-finished products during order production to find the problem earlier if any;

3. Inspection for finished products after production to make sure the products comply with customer’s requirement.

Department Introduction of QC / Technical Support:

In order to get super quality, we have special QC department to control the  product quality. This department is composed by experienced engineers who can offer us strong technical support easily. The engineers will inspect     product quality both in order production and after order production to make sure each shipment we send to our customers is in the best status.  With their strict quality control, our consistent quality wins us more and more orders  from our international customers.

Full Service and Product Warranty:

We offer our customers technical assistance and a full one year warranty on all products covering all manufacturing defects. ME Our manufacturing facility is completely computerized to provide our customers efficiency, reliability, high quality and timely shipments. Spare Parts:We can supply spare parts within 15 business days or sooner. Currently, part numbers are not available on-line. You may however determine the part number from your Parts Book or, if it is a simple part,  you may describe the part and send us an order online. If you are not sure, please Contact Us . Shipm
