China 25hp Sub-Compact Tractor – Ideal for Small-Scale Farming and Garden Work
Discover high-quality China 25hp sub-compact tractor model TS254 designed for efficient farming, gardening, and light construction tasks. With powerful engines, compact designs, and versatile functionality, these tractors are perfect for homeowners, small farm owners, and landscape professionals. Whether you need to plow fields, mow lawns, or transport goods, our sub-compact tractors offer unbeatable performance, durability, and fuel efficiency.
Key features include 4WD capability, diesel or petrol engines, easy-to-use controls, and compatibility with various attachments. Ideal for navigating tight spaces and tackling tasks in smaller areas, these tractors are built to handle a wide range of farming and outdoor jobs.
Explore our selection of China-made sub-compact tractors today and enhance your productivity with reliable, affordable, and powerful machinery.
Hydraulic power steering system, four-wheel drive models can equip full hydraulic steering, that means your steering will be more smooth and flexible, just enjoy your driving. Compact body and small turning radius make it easy to operate, 2-wheel drive 2.8m, 4-wheel drive 3m.
Differential lock provides you better off-road performance.
Chassis designed in mature technology gives you an excellent durable performance.
Anti-rollover safety frame can effectively ensure the safety of the you when the tractor rollover.
Transmission with 8 forward + 2 reverse gears (slip gear shift). You can choose to install the crawling gear structure which could double the number of the gears and provide you better traction. Another transmission with 10 forward + 2 reverse gears (clutch shift) is optional. You can also choose to install the crawling gear structure to make it become 20 forward + 4 reverse gears and provide you better traction. Driving speed covers the range of 0.32-38Km / h, meets the various demands of field working and road transportation.
Equipped with anti-rollover safety frame, which could effectively guarantee the driver`s body safe when the tractor overturns.
Equipped with awnings, your job is no longer limited by the weather.
Model | TS250 Tractor | TS254 Tractor |
Drive Type | 4×2 | 4×4 |
Engine | ||
Engine Manufacturer | Wuzheng Shantuo Engine Co.,Ltd. | Wuzheng Shantuo Engine Co.,Ltd. |
Engine Model | FD295TA | FD295TA |
Engine Type | inline,vertical,water-cooled,four-stroke | inline,vertical,water-cooled,four-stroke |
Cylinder diameter（mm） | 95 | 95 |
Stroke（mm） | 115 | 115 |
Max Torque(N·m)/Revolving Speed(rpm) | ≥96.8/≤1575 | ≥96.8/≤1575 |
Displacement(L) | 1.63 | 1.63 |
Fuel Tank Capacity(L) | 51 | 51 |
Engine Rated Power (kW/rpm) | 18.5 | 18.5 |
Rated Operating Conditions Fuel Consumption Rate(g/kW·h) | ≤250 | ≤250 |
Drive Train | ||
Clutch | Dry,single-stage | Dry,single-stage |
Standard PTO speed(rpm) | (540，1000)/(750，1000)/(540，750) | (540，1000)/(750，1000)/(540，750) |
Gears | 8F+2R/10F+2R | 8F+2R/10F+2R |
Speed range（Km） | 2.24~28.61 | 1.73~22.04 |
Steering type | mechanical steering | hydraulic steering |
Gear Shift Mode | sliding gear shift | sliding gear shift |
Break System | ||
Service Brake | pedal,mechanical drive,closed shoe type | pedal,mechanical drive,closed shoe type |
Parking Brake | locked pedal | locked pedal |
Hydraulic System | ||
Hydraulic Output Flow(L/min) | 30 | 30 |
Hydraulic Output Valve | 1 way(optional) | 1 way(optional) |
Working Device | ||
Three-Point Suspension | postposition,Category I | postposition,Category I |
Max.Lifting Capacity(kN） | ≥4.16 | ≥4.16 |
Tillage Depth Adjustment | position adjustable | position adjustable |
General Parameter | ||
Overall Dimension(L×W×H)mm | With cab | / |
Without cab | 3105×1430×2090 | |
Wheelbase(mm) | 1705 | 1755 |
Min. operating weight(kg) | With cab | / |
Without cab | 1340 | |
Min. Ground Clearance(mm) | 420 | 335 |
Min.turning radius(mm) | 2800 | 3000 |
Maximum Pull（KN） | 5.88 | 7.35 |
Front Tire | 4.0-16 | 6.0-16 |
Rear Tire | 9.5-24 | 9.5-24 |
Optional Disposition | ||
hydraulic steering, | dual-stage clutch, | |
Beifute Company has established an ERP management system and advanced performance testing and chemical testing centers. It has introduced specialized equipment such as spectral analyzers, pressure testing benches, hardness machines, tensile testing machines
Beifute Company has established an ERP management system and advanced performance testing and chemical testing centers. It has introduced specialized equipment such as spectral analyzers, pressure testing benches, hardness machines, tensile testing machines
Main Features ■ Adopt Jianghuai diesel engines, better reliability,more back coefficient for torsion. ■ 10 inch clutch with double actions. ■ Gear-box shows 4X(2+1),namely 8 forwards speed,8 rears speed,exchange in joggle; ■ Driving force output device with postposition,peaceful and stable transmission,stronger bear the weight of loading. ■ Adopt front-wheel turning with full liquid-pressure and independent oil way,turn agilely,reliably,power-saving; ■ Adopt tray-style arrester,stronger brake moment,reliable brake; ■ Adopt semiseparation lifter,plough depth control way is force adjusting,place adjusting,force and place both adjusting. ■ The final driving is planet-gear style,smaller volume,bigger decelerating ratio; ■ Installed adjustable chair with elasticity and shock absorption,comfortable driving. ■ The whole tractor is beautiful,taste,modern,fashion.
The TE chassis tractor is a robust and versatile agricultural machine designed to meet the diverse needs of modern farming. With its advanced features, exceptional performance, and comfortable design, it is ideal for a wide range of field operations.
The TY350/TY354 Tractor from the Mingsin is a highly popular choice for small property owners and hobby farmers who need a compact, reliable tractor for tasks that can’t be handled manually. Perfectly suited for light-duty farm work, the TY350/TY354 is equipped with a front-end loader featuring a versatile 4-in-1 bucket, ideal for cleaning and maintaining your property with ease. Powered by a proven 3-cylinder diesel engine, the TY350/TY354 delivers dependable performance and straightforward serviceability. Whether you're clearing land or tackling other chores, this tractor is built to make your work easier and more efficient.
Model TY300 and TY304 compact tractor boasts a reliable, Laidong diesel engine, a dry-friction, single-disc, dual-stage clutch for smooth operation, and constant-mesh gear engagement. It features responsive hydraulic steering and a Category I/II three-point hitch. The rear-mounted, semi-independent PTO offers speeds of 540/760 RPM or 540/1000 RPM, and includes dual hydraulic outputs for versatile implement use.
