· 8F+2R or 8F+8R Transmission: Smooth shifting for versatile speed control.
· Quick-Shifting Shuttle System: Effortlessly switch between forward/reverse.
· Hydraulic Power Steering: Lightweight design for maneuverability.
· Anti-Rollover Safety Frame: Enhanced driver protection.
· Optional Hydraulic Outputs: Compatible with diverse farm implements.
· Reinforced TE Chassis: Built for heavy-duty tasks and longevity.
· Compact Design: Small turning radius for tight spaces.
· High Traction: Ideal for plowing, mowing, and loader work.
Also belonging to the TE series are MX354-E,MX504-E,Flat-Floor Agricultural Tractor MX504-E.
China Wheel Tractor Model MX454-E
TE454 tractor equipped with the same gearbox and rear axle with the MX454-E tractor, Farm Tractor MX454-E, Lawn Tractor MX454-E, Orchard Tractor MX504-E, Flat-Floor Agricultural Tractor MX504-E, Wheel Tractor MX604-E and Wheel Tractor MX804-E. The TE Chassis Tractor TE454 is engineered for demanding agricultural operations, combining rugged durability with advanced functionality. Built on a reinforced TE chassis with high-quality materials, this tractor excels in heavy-duty tasks like plowing, mowing, and loader work. Its 8 forward and 8 reverse gears provide a wide speed range (2.59–29.42 km/h), adapting seamlessly to varying terrain and implement requirements.
Key features include a quick-shifting shuttle system for instant directional changes, hydraulic power steering for effortless control, and an optional dual-speed PTO (540/1000 RPM) to power attachments like mowers and trailers. The anti-rollover safety frame and optional enclosed cab prioritize operator safety, while the compact design ensures agility in confined spaces.
Powered by a 33.1 kW JD495BT3 engine (3.17L displacement), the TE450/TE454 delivers reliable performance with low fuel consumption (≤245 g/kW·h). Choose between 4x2 (TS450) or 4x4 (TS454) drive types for enhanced traction on challenging terrain. With optional configurations like paddy tires, air brakes, and hydraulic outputs, this tractor is a versatile solution for global farming needs.
Features:
8F+8R Transmission: Smooth shifting for versatile speed control.
Quick-Shifting Shuttle System: Effortlessly switch between forward/reverse.
Hydraulic Power Steering: Lightweight design for maneuverability.
Anti-Rollover Safety Frame: Enhanced driver protection.
Optional Hydraulic Outputs: Compatible with diverse farm implements.
Reinforced TE Chassis: Built for heavy-duty tasks and longevity.
Compact Design: Small turning radius for tight spaces.
High Traction: Ideal for plowing, mowing, and loader work.
Technical Specifications:
Item | Unit | Parameters | ||
Tractor body | Model | / | TE454 | |
Type | / | 4×2 or 4×4 wheeled tractor | ||
Purpose | / | Farm work, transportation | ||
Overall dimensions (LxWxH) | mm | 3350×1610×1900 | ||
Axle distance or track ground length | mm | 1870 | ||
Wheelbase (front/rear) or track gauge | mm | 1000~1300/1000~1300 | ||
Wheelbase adjustment (front/rear) | / | Front wheels stepwise adjustable/rear wheels stepless adjustable | ||
Minimum ground clearance | mm | 330 | ||
Minimum useable mass | kg | 1214 | ||
Mass of front axle/mass of rear axle (without counterweight) | kg | 486/728 | ||
Maximum counterweight mass (front/rear) | kg | 30/90 | ||
Number of gears (forward/reverse) | / | 8F+2R or 8F+8F | ||
Theoretical speed in each gear | km/h | Forward:Ⅰ 2.07;Ⅱ 3.26;Ⅲ 4.95; Ⅳ 6.87; Ⅴ 9.57; Ⅵ 14.58; Ⅶ 22.87;Ⅷ 31.54 | ||
Connection between engine and clutch | / | Direct connection | ||
Starting method | / | Electric start | ||
Power output shaft power | kw | ≥18.8 | ||
Max. Traction force | kN | ≥5.9 | ||
Engine | Trademark or Brand | / | Laidong | |
Model | / | Inline, water-cooled, vertical, four-stroke | ||
Intake | / | Naturally aspirated | ||
Number of Cylinders | 缸 | 4 | ||
Calibrated Power | kw | 33.1kw | ||
Calibrated RPM | r/min | 2350 | ||
Injector Pump Model/Type | / | VE3/10E1175RLD03/Single acting plunger type | ||
Injector Model/Type | / | KBAL-P043 perforated type | ||
Injector Manufacturer | / | / | ||
Supercharger Model/Manufacturer EGR Model/Type | / | / | ||
ECU Model/Type | / | D26A-81-10 | ||
Catalytic Converter Model | / | / | ||
Intercooler Model | / | / | ||
Air Filter Model/Type | / | Oil bath type、TF500 | ||
Starter Motor Model | / | QD139 | ||
Cooling System Type | / | Forced water cooling | ||
Driver's seat | Specification Model | / | 629 | |
Suspension Type | / | Stationary | ||
Muffler | Muffler Chamber Dimensions (L x W x Thickness or Diameter x Length) | mm | φ100*453 | |
Mass | kg | 3.2 | ||
Steering, braking system | Steering System Type | / | Fully hydraulic steering | |
Steering Gear Type | / | Pendulum rotary-valve hydrostatic steering | ||
Brake System Type | / | Mechanical, hoofed | ||
Transmission system | Clutch Type | / | Single-piece, dry, single-acting/dry, double-acting | |
Transmission Type | / | (4+1)×2 composition | ||
Transmission Shift Type | / | Engaged bushing wheel shift | ||
Central Transmission Type (front/rear) | / | Spiral bevel gear | ||
Differential Transmission Type (front/rear) | / | Two planetary gears, enclosed | ||
Final Drive Type (front/rear) | / | Built-in, single-stage spur gears | ||
Traveling system | Frame type | / | Semi-framed | |
Wheel type | Tire (Front/Rear) | / | 6.00-16/9.5-24;650-16/11.2-24 | |
Air pressure(Front/Rear) | kpa | Field: 120/150 Transportation: 150/180 | ||
Material of wheel rim | / | Q215 | ||
Working device | Hydraulic suspension system type | / | Semi-split | |
Suspension device type | / | Rear, three-point suspension | ||
Suspension device category | / | Class 1 | ||
Adjustment method | / | Bit adjustment | ||
Hydraulic oil pump type and model | / | Gear pump, CBN-E34 | ||
Hydraulic output device | / | Simple hydraulic output | ||
Safety valve full opening pressure | Mpa | 16±0.5 | ||
Power output shaft type | / | Rear, non-independent | ||
Number of splines on power output shaft | / | 6-tooth | ||
Outer diameter of splines on power output shaft | mm | φ35 | ||
Speed of power output shaft | r/min | 720/540 | ||
Maximum lifting force at 610 mm on the frame | kN | ≥5.0 | ||
